Outdoor Street Fiber Kabinlər – Model 01A

MODEL	O1A
PRODUCT: FIBRE STREET CABINET	FSC
FIBRES	576, 512, 288
DOORS: DOUBLE OR SINGLE	DD, SD
IP RATING	I65
SIZE: 1450X360	143
COLOUR: BLACK, GREY, BEIGE	K, G, B

Təhlükəsiz alış-veriş

Tətbiq sahəsi

Material	Outer: 3 mm Aluminium (single skin) Rails: 2 mm AISI304 stainless
Dimensions	1450 (w) x 1545 (h) x 360 (d) mm
Adapter Port	SC Simplex
Splitter Option	16 x 1:8 PLC splitter or 10 x 1:16 PLC splitter
Max. Capacity	576 Fibres
Max Unit Height	26 U
Cable Glands	10 × PG29 plus 10 × PG21
Cable Entry	2 × Skid Cable Entry
Locking System	3-point locking system
Max Splice Tray Qty	48 pcs
Rating	IP65 and IK10 rating
